2022 KLX230R S
Kawasaki 2022 KLX230R S for Sale at Ultimate Kawasaki Springwood in Springwood, QLD | Specifications and Review Information
Take trail adventuring to the next level. With long travel suspension, and ample ground clearance, KLX230R lightweight, full-size recreational trail bikes are purpose-built for serious fun in the dirt.
FEATURING:
- 233cc FUEL-INJECTED, AIR-COOLED FOUR-STROKE SINGLE
- CAPABLE OFF-ROAD PERFORMANCE
- TRAIL-TUNED LONG TRAVEL SUSPENSION
STEADY POWER
GO PLAY
The KLX230R recreational off-road motorcycle is powered by a 233cc fuel-injected, air-cooled single, tuned for low- to mid-range power.
RUGGED CHASSIS
BUILT TOUGH
Designing the engine and chassis at the same time was key to making the KLX230R play bike as agile, balanced and reliable as possible, appealing to new riders and fun for experienced riders.
HIGH-PERFORMANCE CAPABILITY
TAKE ON THE TRAILS
Designed from the ground up for dirt fun. That's why the KLX230R off-road motorcycle features long-travel suspension, front and rear disc brakes and full-size wheels.
TRAIL-RIDING PERFORMANCE
BLAZE YOUR OWN TRAILS
With long-travel suspension, light weight and ample ground clearance, the KLX230R is the ideal off-road adventure partner for pure off-road performance.
| Model | KLX230R S |
| Engine Type | 4-stroke, Single |
| Displacement | 233 cm3 |
| Bore X Stroke | 67.0 x 66.0 mm |
| Compression Ratio | 9.4:1 |
| Valve System | SOHC 2 valve |
| Fuel System | Fuel Injection (32 x 1) |
| Ignition | Digital |
| Starting | Electric |
| Transmission | 6-speed, return |
| Clutch | Wet multi-disc, manual |
| Wheel Travel - front | 220 mm |
| Wheel Travel - rear | 223 mm |
| Tyre Size-front | 80/100-21 51M |
| Tyre Size-rear | 100/100-18 59M |
| Suspension - front | 37 mm telescopic fork |
| Suspension - rear | Uni Trak Swingarm |
| Brakes - front | 240 mm single disk |
| Brakes - front | 220 mm petal disk |
| L X W X H | 2,035 x 840 x 1175 mm |
| Wheelbase | 1,350 mm |
| Ground Clearance | 275 mm |
| Seat Height | 900 mm |
| Fuel Capacity | 6.6 litres |
| Curb Mass | 115 kg |
| Colour | Lime Green |
